GL-18HL Panasonic Inductive Proximity Sensor

Sensing Distance 20 mm Usage For Industrial Output PNP Voltage 24 V Current 15mA Switching Function Normally open (NO) Brand Panasonic Sensor Type Inductive Proximity Sensor Model Name/Number GL-18HL Product Type Sensor Usage/Application Industrial Response frequency 50 / 60 Hz Power supply voltage 10 ...... 30 V Control output PNP Protection circuits IP67 Operating Frequency 60 Hz Maximum Switching Current 15 mA Body Material Stainless Steel Material Nickel Coated Brass Product Number GL-18HL Part Number GL-18HL Products Name Compact & Low Price Inductive Proximity Sensor Product details GL-18H/18HL type The price of the product Please contact our office CE marking directive compliance EMC Directive, RoHS Directive Max. operation distance 12 mm 0.472 in ± 10 % (Note)The maximum operation distance stands for the maximum distance for which the sensor can detect the standard sensing object.The stable sensing range stands for the sensing range for which the sensor can stably detect the standard sensing object even if there is an ambient temperature drift and/or supply voltage fluctuation. Stable sensing range 0 to 10 mm 0 to 0.394 in (Note)The maximum operation distance stands for the maximum distance for which the sensor can detect the standard sensing object.The stable sensing range stands for the sensing range for which the sensor can stably detect the standard sensing object even if there is an ambient temperature drift and/or supply voltage fluctuation.
