GL-N12H-P Panasonic Inductive Proximity Sensor

Sensing Distance 20 mm Usage For Industrial Output PNP Voltage 24 V Current 15mA Switching Function Normally open (NO) Brand Panasonic Sensor Type Inductive Proximity Sensor Model Name/Number GL-N12H-P Product Type Sensor Usage/Application Industrial Response frequency 60 Hz Power supply voltage 240 V Control output PNP Protection circuits IP20 Body Material Stainless Steel Material Plastic GL-N12H-P Panasonic? ? ? ? ? ? ? ? ? ? ? ? ? ? This product has been developed / produced for industrial use only. Make sure that the power supply is off while wiring. Take care that wrong wiring will damage the sensor. Verify that the supply voltage variation is within the rating. If power is supplied from a commercial switching regulator, ensure that the frame ground (F.G.) terminal of the power supply is connected to an actual ground. In case noise generating equipment (switching regulator, inverter motor, etc.) is used in the vicinity of this product, connect the frame ground (F.G.) terminal of the equipment to an actual ground. Do not run the wires together with high-voltage lines or power lines or put them in the same raceway. This can cause malfunction due to induction. Extension up to total 100m is possible with a 0.3mm2, or more, cable. Do not use during the initial transient time (50ms) after the power supply is switched on. Take care that the product does not come in contact with oil, grease, organic solvents, such as, thinner etc., or strong acid, and alkaline. Make sure that stress by forcible bend or pulling is not applied to the sensor cable joint. Since the cable end is not waterproof, do not use the sensor in the application where water may seep in from the cable end. Make sure that the sensing end is not covered with metal dust, scrap or spatter. It will result in malfunction. Never disassemble or modify this sensor. It will get damaged.
