GRT1-DA2C Omron Analog Output Module

Number of Channels 8 Usage/Application Industrial Model Name/Number GRT1-DA2C Ambient Temperature -25 ...... 75 C Power 5 A Packaging Type Box Phase 3 Phase Product Type Module Module Type Analog Output Module Mounting 35 nm Accuracy 100 % Color Black Weight 43 g GRT1-DA2C Omron Analog Output Module Unit power supply voltage 24 VDC (20.4 to 26.4 VDC) I/O power supply voltage 24 VDC (20.4 to 26.4 VDC) I/O connection Screwless push-in technology Noise immunity Conforms to IEC61000-4-4, 2.0 kV (power supply line) Vibration resistance 10 to 60 Hz: 0.7 mm double amplitude 60 to 150 Hz: 50 m/s2 Shock resistance 150 m/s2, 3 times in each direction Dielectric strength 500 VAC (between isolated circuits) Insulation resistance 20 M? min. (between isolated circuits) Ambient operating temperature -10 to 55°C (with no icing or condensation) Ambient operating humidity 25% to 85% Operating environment No corrosive gases Ambient storage temperature -25 to 65°C (with no icing or condensation) Mounting 35 mm DIN rail
