GRTE18-P1142 Sick Photoelectric Sensor

Features Functional principle =Photoelectric proximity sensor Functional principle detail =Energetic Dimensions =(W x H x D) 18 mm x 18 mm x 71.5 mm Housing design (light emission) =Cylindrical Thread diameter (housing) =M18 x 1 Optical axis =Axial Sensing range max =5 mm ... 550 mm Sensing range =10 mm ... 400 mm Type of light =Visible red light Light source =PinPoint LED Light spot size (distance) =Ø 9 mm (400 mm) Wave length =650 nm Adjustment =Potentiometer, 270° Supply voltage =10 V DC ... 30 V DC Switching output =PNP Indication =LED green:Operating indicator Static on:power on =LED yellow:Status of received light beam Static on: object present Static off: object not present 1) Object with 90% remission (based on standard white, DIN 5033). 2) Average service life: 100,000 h at TU = +25 °C.
