GS6-D1311 Sick Photoelectric Sensor

Sensor Type Through-Beam Sensing Mode Through-Beam Sensing range max. 0...15 Sensing range 0...10 Wave length 650 Supply voltage UB 0 V DC ... 30 V DC Functional principle Through-beam photoelectric sensorSensing range max. 0 m ... 15 mSensing range 0 m ... 10 mPolarisation filters NoEmitted beamLight source PinPoint LED 1)Type of light Visible red lightLight spot size (distance) Ø 375 mm (12 m)Key LED figuresWave length 650 nmAdjustment Potentiometer, 270°Part number of individual components 2058063 GS6-D1311 2066446 GE6-N12111) Average service life: 100,000 h at TU = +25 °C.Electrical dataSupply voltage UB 10 V DC ... 30 V DC 1)Ripple ± 10 % 2)Current consumption 30 mA 3)Protection class III1) Limit values when operated in short-circuit protected network: max. 8 A.2) May not fall below or exceed UV tolerances.3) Without load.4) At Uv > 24 V, IA max. = 50 mA.5) Signal transit time with resistive load.6) With light/dark ratio 1:1.7) A = VS connections reverse-polarity protected.8) B = inputs and output reverse-polarity protected.9) D = outputs overcurrent and short-circuit protected.2 PHOTOELECTRIC SENSORS | SICK Product data sheet | 2024-11-26 17:17:33Subject to change without noticeGSE6-N1211 | G6MINIATURE PHOTOELECTRIC SENSORSDigital outputType NPNSwitching mode Light/dark switchingSwitching mode selector Selectable via light/dark selectorSignal voltage PNP HIGH/LOW Approx. VS / ? 3 VOutput current Imax. ? 100 mA 4)Response time < 500 ?s 5)Switching frequency 1,000 Hz 6)Circuit protection A 7)B 8)D 9)1) Limit values when operated in short-circuit protected network: max. 8 A.2) May not fall below or exceed UV tolerances.3) Without load.4) At Uv > 24 V, IA max. = 50 mA.5) Signal transit time with resistive load.6) With light/dark ratio 1:1.7) A = VS connections reverse-polarity protected.8) B = inputs and output reverse-polarity protected.9) D = outputs overcurrent and short-circuit protected.Mechanical dataHousing RectangularDimensions (W x H x D) 12 mm x 31.5 mm x 21 mmConnection Cable, 3-wire, 2 m 1)Connection detailConductor size 0.14 mm²Length of cable (L) 2 m 1)MaterialHousing Plastic, ABS/PCFront screen Plastic, PMMACable Plastic, PVCWeight 170 g1) Do not bend below 0 °C.Ambient dataEnclosure rating IP67Ambient operating temperature –25 °C ... +55 °C 1)Ambient temperature, storage –40 °C ... +70 °CUL File No. NRKH.E348498 & NRKH7.E3484981) Temperature stability following adjustment +/-10 °C.Classificat
