GX-130MKA Panasonic Proximity Sensor

Sensing Distance 20 mm Usage For Industrial Output PNP Voltage 24 V Current 15mA Switching Function Normally open (NO) Brand Panasonic Sensor Type Proximity Sensor Model Name/Number GX-130MKA Product Type Sensor Usage/Application Industrial Power supply voltage 12 ....... 24 V Protection circuits IP65 Power 10 A Temperature -20 ........ 70 C Accuracy 100 % Body Material Stainless Steel Material Plastic Max. response frequency 5 kHz 5 kHz 2 kHz 1 kHz Operation indicator Yellow LED (lights up when the output is ON) Pollution degree 3 (industrial enviroment) Protection IP67 (IEC) IP69K (DIN), IP68 (IEC) (2 m cable length type only), IP67 (IEC) (M12 plug-in connector type only) Ambient temperature –25 to +70 ? –13 to +158 ?, Storage: –40 to +85 ? –40 to +185 ? Ambient humidity 50 % RH or less (at +70 ? +158 ?) Voltage withstandability 500 V AC for one min. between all supply terminals connected together and enclosure Vibration resistance 10 to 55 Hz frequency, 0.5 mm 0.02 in double amplitude in X, Y and Z directions for 1.5 hours each Shock resistance 294 m/s2 acceleration (30 G approx.) in X, Y and Z directions three times each
