GX-H8B Panasonic Proximity Sensor

Type Proximity Sensor Usage For Security Body Material PBT plastic Accuracy 100% Brand Panasonic Sensor Type Proximity Sensor Model Name/Number GX-H8B Product Type Sensor Usage/Application Industrial Operating Frequency 500 Hz Sensing Distance 10 mm Active Area 8 mm Product Number GX-H8B Part Number GX-H8B Products Name Rectangular-shaped Inductive Proximity Sensor Product details NPN output The price of the product Please contact our office Max. operation distance 2.5 mm 0.098 in plus or minus 8 % (Note) The maximum operation distance stands for the maximum distance for which the sensor can detect the standard sensing object. Stable sensing range 0 to 2.1 mm 0 to 0.083 in (Note) The stable sensing range stands for the sensing range for which the sensor can stably detect the standard sensing object even if there is an ambient temperature drift and/or supply voltage fluctuation. Standard sensing object Iron sheet 15 × 15 × t 1 mm 0.591 × 0.591 × t 0.039 in Applicable regulations and certifications CE Marking (EMC Directive, RoHS Directive), UKCA Marking (EMC Regulations, RoHS Regulations) Hysteresis 20 % or less of operation distance(with standard sensing object) Repeatability Along sensing axis, perpendicular to sensing axis: 0.04 mm 0.002 in or less Supply voltage 12 to 24 V DC +10/-15 % Ripple P-P 10 % or less Current consumption 15 mA or less Output NPN open-collector transistor - Maximum sink current: 100 mA - Applied voltage: 30 V DC or less (between output and 0 V) - Residual voltage: 2 V or less (at 100 mA sink current) Output:Output operation Normally closed Output:Utilization category DC-12 or DC-13 Max. response frequency 500 Hz
