H3DKZ-F Omron Solid-State Timer

Number Of Poles 4 Pole Material Plastic Usage/Application Relay Modules Model Name/Number H3DKZ-F Coil Voltage 240 V Voltage Type AC Current .25 mA Relay Type Signal Relays, General Purpose Relays Power Consumption 24 ...... 240 V Product Type Solid-state Timer Brand Omron Color White Weight 110 g Rated power supply voltage 24 to 240 VAC 50/60 Hz 24 to 240 VDC Ripple 20% max. Allowable voltage variable range 85 to 110% of the power supply voltage Power consumption Approx. 4.5 VA (at 240 VAC) Reset voltage 10% max. of rated supply voltage Number of time ranges 8 Operation mode Flicker OFF start, Flicker ON start Control output (Type) Relay output (SPDT) Control output (Contact output) Resistive load: 250 VAC 5 A (cos?=1)/5 A at 30 VDC/0.5 A max. at 125 VDC Minimum applicable load: 10 mA at 5 VDC (failure level: P Reference value) Ambient temperature range Operating: -20 to 55 ? (with no icing) Storage: -40 to 70 ? (with no icing) Ambient humidity range Operating: 25 to 85 %
