H3YN-21 DC24 Omron Solid-State Timer

Number Of Poles 4 Pole Material Plastic Usage/Application Relay Modules Model Name/Number H3YN-21 DC24 Coil Voltage 24 V DC Voltage Type DC Current 1.5 mA Weight 57 g Brand Omron Rated power supply voltage 24 VDC If power supply incorporates a single-phase full-wave rectifier. Allowable voltage variable range 85 to 110% of the power supply voltage Power consumption Relay ON: Approx. 1.1 W (at 24 VDC)/Relay OFF: Approx. 0.1 W (at 24 VDC) Reset voltage 10% max. of rated supply voltage Number of time ranges 4 Operation mode ON delay, Interval, Flicker OFF start, Flicker ON start Control output (Type) Time-limit: DPDT Control output (Contact output) Resistive load: 250 VAC 5 A (cos?=1) Minimum applicable load: 1 mA at 5 VDC (failure level: P) Ambient temperature range Operating: -10 to 50 ? (with no icing) Storage: -25 to 65 ? (with no icing) Ambient humidity range Operating: 35 to 85 % Accuracy of operating time ±1% FS max.
