IES222 IFM Inductive Sensor

Sensing Distance 5 mm Usage For Industrial Output NPN Current 10mA Switching Function Normally open (NO) Brand IFM Sensor Type Inductive Sensor Model Name/Number IES222 Product Type Sensor Dimension M8 x 1 / L = 30 Usage/Application Industrial Response frequency 25 Hz Power supply voltage 10 - 30 V Control output NPN Protection circuits IP65 Operating Frequency 800 Hz Power 10 Hz Dimension (W x H x L) M8 x 1 / L = 30 Leakage Current Load 30 mA Maximum Switching Current 25 mA Color Silver Weight 29 g Accuracy 100 % Body Material Stainless Steel Material Plastic Inductive sensorIES222IEB3006-BNKG/V4A/AS Suitable for industrial, mobile, cooling and lubricating applications High protection rating for the requirements of harsh industrial environments Flexible use thanks to large operating temperature range Safe detection due to large sensing range and low sensor tolerances Reduced storage due to wide range of applications
