IES229 IFM Inductive Sensor

Sensing Distance 5 mm Usage For Industrial Output PNP Voltage 30 V Current 15mA Switching Function Normally open (NO) Brand IFM Sensor Type Inductive Sensor Model Name/Number IES229 Product Type Sensor Usage/Application Industrial Dimension M8 x 1 / L = 37.5 Response frequency 50 / 60 Hz Power supply voltage 10 ..... 30 V Control output PNP Protection circuits IP65 Operating Frequency 800 Power 5 A Maximum Switching Current 15 mA Weight 33.5 g Body Material Stainless Steel Material Plastic Leakage Current Load 10 mA Inductive sensorIES229IEB3003BBPKG/V4A/K1/0,5M/US Suitable for industrial, mobile, cooling and lubricating applications High protection rating for the requirements of harsh industrial environments Correction factor 1: Constant sensing range on all metals Very high switching frequency Vibration and shock resistant
