IES232 IFM Inductive Sensor

Sensing Distance 5 mm Usage For Industrial Output PNP Voltage 24 V Switching Function Normally open (NO) Brand IFM Sensor Type Inductive Sensor Model Name/Number IES232 Product Type Sensor Dimension M8 x 1 / L = 50 Usage/Application Industrial Response frequency 50 Hz Power supply voltage 10 - 30 V Control output PNP Protection circuits IP67 Operating Frequency 800 Hz Power 10 A Dimension (W x H x L) M8 x 1 / L = 50 Leakage Current Load 30 mA Color Silver Weight 16.8 g Accuracy 100 % Body Material Stainless Steel Current 5mA Material Plastic Maximum Switching Current 20 mA Inductive sensorIES232IEB3006-BPKG/V4A/US-104 Suitable for industrial, mobile, cooling and lubricating applications High protection rating for the requirements of harsh industrial environments Flexible use thanks to large operating temperature range Safe detection due to large sensing range and low sensor tolerances Reduced storage due to wide range of applications
