IF6137 IFM Inductive Sensor

Sensing Distance 8 mm Usage For Industrial Output PNP Voltage 30 V Switching Function Normally open (NO) Brand IFM Sensor Type Inductive Sensor Model Name/Number IF6137 Product Type Sensor Usage/Application Industrial Dimension M12 x 1 / L = 60 Response frequency 50 Hz Power supply voltage 10 ------ 30 V Control output PNP Protection circuits IP67 Operating Frequency 100 Power 10 A Dimension (W x H x L) M12 x 1 / L = 60 Leakage Current Load 30 mA Body Material Stainless Steel Current 5mA Material Plastic Maximum Switching Current 10 mA Inductive sensor with IO-LinkIF6137IFK4004BFRKG/IO/US-104 For a precise position monitoring on machines Flexible use thanks to large operating temperature range Very high repeatability Reliable transmission of the distance as linearised process value via IO-Link Normally closed / normally open and PNP/NPN adjustable via IO-Link
