IFC211 IFM Inductive Sensor

Sensing Distance 2.5 mm Usage For Industrial Body Material Stainless Steel Output PNP Voltage 30 V Current 15mA Switching Function Normally open (NO) Brand IFM Sensor Type Inductive Sensor Model Name/Number IFC211 Product Type Sensor Material Plastic Dimension M12 x 1 / L = 70 Usage/Application Industrial Response frequency 25 Power supply voltage 250 V Protection circuits IP 67 Operating Frequency 25 Dimension (W x H x L) M12 x 1 / L = 70 Maximum Switching Current 30 mA Inductive sensorIFC211IFK3003-BPKG/M/US-104-DPS/K0Product characteristics Electrical design PNP Output function normally open Sensing range [mm] 3 Housing threaded type Dimensions [mm] M12 x 1 / L = 70 Application Special feature Gold-plated contacts; Increased sensing range Application Use in machine tools, coolants and lubricants Media ferrous only; aluminium chip immune Electrical data Operating voltage [V] 10...30 DC Current consumption [mA] < 10 Protection class III Reverse polarity protection yes Outputs Electrical design PNP Output function normally open
