IFC277 IFM Inductive Sensor

Sensing Distance 20 mm Usage For Industrial Output PNP Voltage 30 V Current 5mA Switching Function Normally open (NO) Brand IFM Sensor Type Inductive Sensor Model Name/Number IFC277 Product Type Sensor Usage/Application Industrial Dimension M12 x 1 / L = 60 Response frequency 50 / 60 Hz Power supply voltage 10 ...... 30 V Control output PNP Protection circuits IP65 Operating Frequency 100 Power 5 A Dimension (W x H x L) M12 x 1 / L = 60 Maximum Switching Current 30 mA Weight 29.4 g Color Silver Body Material Stainless Steel Material Plastic Inductive full-metal sensorIFC277IFK3004BFRKG/AM/IO/US-104 For a precise position monitoring on machines Flexible use thanks to large operating temperature range Very high repeatability Reliable transmission of the distance as linearised process value via IO-Link Normally closed / normally open and PNP/NPN adjustable via IO-Link
