IFM206 IFM Inductive Sensor

Sensing Distance 8 mm Usage For Industrial Output PNP Voltage 30 V Switching Function Normally open (NO) Brand IFM Sensor Type Inductive Sensor Model Name/Number IFM206 Product Type Sensor Usage/Application Industrial Dimension M12 x 1 / L = 70 Response frequency 60 Hz Power supply voltage 10 - 30 V Control output PNP Protection circuits IP65 Operating Frequency 50 / 60 Hz Power 5 A Dimension (W x H x L) M12 x 1 / L = 70 Maximum Switching Current 30 mA Weight 29.8 g Accuracy 100 % Body Material Stainless Steel Current 5mA Material Plastic Leakage Current Load 20 mA Inductive sensorIFM206IFK3007-BPKG/60V/V4A/US-104 High shock and vibration resistance for use in mobile machines E1 type approval by the Kraftfahrt-Bundesamt (German Federal Motor Transport Authority) Large operating temperature and operating voltage range High ingress protection for the requirements of harsh environmental conditions
