IFS257 IFM Inductive Sensor

Sensing Distance 15 mm Usage For Industrial Output PNP Voltage 30 V Switching Function Normally open (NO) Brand IFM Sensor Type Inductive Sensor Model Name/Number IFS257 Product Type Sensor Dimension M12 x 1 / L = 40 Usage/Application Industrial Response frequency 50/60 Hz Power supply voltage 10 - 30 V Control output PNP Protection circuits IP67 Operating Frequency 50 / 60 Hz Power 10 A Dimension (W x H x L) M12 x 1 / L = 40 Maximum Switching Current 30 mA Operating voltage 10 ...... 30 V Ambient temperature -40 ........ +85 C Body Material Stainless Steel Current 10mA Material Plastic Leakage Current Load 20 mA Inductive sensorIFS257IFB3007-BPKG/2M/PURVersionsIFS2572 m PUR-Cable Suitable for industrial, mobile, cooling and lubricating applications High protection rating for the requirements of harsh industrial environments Flexible use thanks to large operating temperature range Safe detection due to large sensing range and low sensor tolerances Reduced storage due to wide range of applications
