IG5565 IFM Inductive Sensor

Sensing Distance 8 mm Usage For Industrial Body Material PBT plastic Output PNP Voltage 30 V Current 10mA Switching Function Normally open (NO) Brand IFM Sensor Type Inductive Sensor Model Name/Number IG5565 Product Type Sensor Material Plastic Usage/Application Industrial Dimension M18 x 1 / L = 80 Response frequency 50 Hz Power supply voltage 10 - 30 V Control output PNP Protection circuits IP68 Operating Frequency 300 Hz Power 10 A Dimension (W x H x L) M18 x 1 / L = 80 Maximum Switching Current 35 mA Color Orange Accuracy 100 % Weight 395.3 g Inductive sensorIG5565IG-2008-FRKG/10M/PHVersionsIG55652 m PUR / PVC-Cable6 m PUR / PVC-Cable10 m PUR / PVC-Cable Output function normally open / normally closed programmable Two-wire technology Large operating voltage range High protection rating for the requirements of harsh industrial environments Wide operating temperature range
