IG5567 IFM Inductive Sensor

Sensing Distance 5 mm Usage For Industrial Body Material Stainless Steel Output PNP Voltage 30 V Current 15mA Switching Function Normally open (NO) Brand IFM Sensor Type Inductive Sensor Model Name/Number IG5567 Product Type Sensor Material Plastic Dimension M18 x 1 / L = 76 Usage/Application Industrial Response frequency 500 Power supply voltage 250 V Protection circuits IP 65 Operating Frequency 500 Dimension (W x H x L) M18 x 1 / L = 76 Maximum Switching Current 30 mA Weight 120 Product characteristics Electrical design PNP Output function normally open Sensing range [mm] 5 Housing threaded type Dimensions [mm] M18 x 1 / L = 76 Electrical data Operating voltage [V] 10...30 DC Current consumption [mA] 5; (24 V) Protection class II Reverse polarity protection no Outputs Electrical design PNP Output function normally open Max. voltage drop switching output DC [V] 2.5 Permanent current rating of switching output DC [mA] 200 Switching frequency DC [Hz] 500 Short-circuit protection no Overload protection no Detection zone Sensing range [mm] 5 Real sensing range Sr [mm] 5 ± 10 % Operating distance [mm] 0...4.05 Accuracy / deviations Correction factor steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminium: 0.3 / copper: 0.3
