IG5682 IFM Inductive Sensor

Sensing Distance 5 mm Usage For Industrial Body Material Stainless Steel Output PNP Voltage 30 V Current 10mA Switching Function Normally open (NO) Brand IFM Sensor Type Inductive Sensor Model Name/Number IG5682 Product Type Sensor Material Plastic Dimension M18 x 1 / L = 54 Usage/Application Industrial Response frequency 50 Hz Power supply voltage 10 ....... 55 C Control output PNP Protection circuits IP67 Operating Frequency 700 HZ Power 10 A Dimension (W x H x L) M18 x 1 / L = 54 Leakage Current Load 30 mA Maximum Switching Current 20 mA Color Silver Weight 110.2 g Protection IP 67 Sensing range 5 Inductive sensorIG5682IGB2005-ARKG/UP/PUR RT Two-wire technology Robust metal housing for use in harsh industrial environments Large operating temperature and operating voltage range Very high switching frequency
