IGS283 IFM Inductive Sensor

Sensing Distance 8 mm Usage For Industrial Body Material Stainless Steel Output PNP Voltage 30 V Current 10mA Switching Function Normally open (NO) Brand IFM Sensor Type Inductive Sensor Model Name/Number IGS283 Product Type Sensor Material Plastic Usage/Application Industrial Dimension M18 x 1 / L = 60 Response frequency 50 Hz Power supply voltage 10 ..... 32 V Control output PNP Protection circuits IP56 Operating Frequency 400 Hz Power 10 A Dimension (W x H x L) M18 x 1 / L = 60 Leakage Current Load 20 mA Maximum Switching Current 35 mA Color Silver Weight 219.2 g Inductive sensorIGS283IGK3008BBPKG/5M/PURVersionsIGS2832 m PUR-Cable5 m PUR-Cable Suitable for industrial, mobile, cooling and lubricating applications High protection rating for the requirements of harsh industrial environments Flexible use thanks to large operating temperature range Safe detection due to large sensing range and low sensor tolerances Reduced storage due to wide range of applications
