II0094 IFM Inductive Sensor

Sensing Distance 15 mm Usage For Industrial Body Material Stainless Steel Output PNP Voltage 30 V Current 15mA Switching Function Normally open (NO) Brand IFM Sensor Type Inductive Sensor Model Name/Number II0094 Product Type Sensor Material Plastic Usage/Application Industrial Dimension M30 x 1.5 / L = 81 Response frequency 25 Hz Power supply voltage 10 ........ 30 V Control output PNP Protection circuits IP67 Operating Frequency 50 Hz Power 10 A Dimension (W x H x L) M30 x 1.5 / L = 81 Leakage Current Load 35 mA Maximum Switching Current 15 mA Color Orange Weight 180.5 g Accuracy 100 % Inductive sensorII0094II-2010-BBOA With combined AC/DC output stage Large operating voltage range Two-wire technology Wide operating temperature range High protection rating for the requirements of harsh industrial environments
