II5983 IFM Inductive Sensor

Sensing Distance 5 mm Usage For Industrial Output NPN Voltage 30 V Switching Function Normally open (NO) Brand IFM Sensor Type Inductive Sensor Model Name/Number II5983 Product Type Sensor Dimension M30 x 1.5 / L = 65 Usage/Application Industrial Response frequency 50 / 60 Hz Power supply voltage 10 - 30 V Control output NPN Protection circuits IP67 Operating Frequency 50 Hz Power 5 A Dimension (W x H x L) M30 x 1.5 / L = 65 Maximum Switching Current 30 mA Color Silver Body Material Stainless Steel Current 5mA Material Plastic Leakage Current Load 10 mA Inductive sensor with IO-LinkII5983IIK4012BFRKG/IO/US-104 Long sensing range for use in conveying Flexible use thanks to large operating temperature range Reliable transmission of the distance as linearised process value via IO-Link Normally closed / normally open and PNP/NPN adjustable via IO-Link
