IIC228 IFM Inductive Sensor

Sensing Distance 20 mm Usage For Industrial Output PNP Voltage 30 V Current 15mA Switching Function Normally open (NO) Brand IFM Sensor Type Inductive Sensor Model Name/Number IIC228 Product Type Sensor Usage/Application Industrial Dimension M30 x 1.5 / L = 65 Response frequency 50 Hz Power supply voltage 10 ....... 30 V Control output PNP Protection circuits IP67 Operating Frequency 50 / 60 Hz Power 5 A Dimension (W x H x L) M30 x 1.5 / L = 65 Leakage Current Load 15 mA Maximum Switching Current 40 mA Body Material Stainless Steel Material Plastic Inductive full-metal sensorIIC228IIK3010-APKG/AM/US-104 For use in machine tools and metalworking Resistant to oils and coolants Metal sensing face for heavy duty Clearly visible indication of the switching status Permanently legible laser type label
