IIM208 IFM Inductive Sensor

Sensing Distance 15 mm Usage For Industrial Output PNP Voltage 30 V Switching Function Normally closed (NC) Brand IFM Sensor Type Sensor Model Name/Number IIM208 Product Type Sensor Dimension M30 x 1.5 / L = 70 Usage/Application Industrial Response frequency 60 Hz Power supply voltage 10 - 36 V Control output PNP Protection circuits IP65 Operating Frequency 60 Hz Power 5 A Dimension (W x H x L) M30 x 1.5 / L = 70 Maximum Switching Current 30 mA Body Material Stainless Steel Current 5mA Material Plastic Leakage Current Load 10 mA Inductive sensorIIM208IIK3012BBPKG/M/60V/US-104 E1 type approval by the Kraftfahrt-Bundesamt (German Federal Motor Transport Authority) Wide operating temperature range High ingress protection for the requirements of harsh environmental conditions High EMC resistance according to automotive standards Large operating voltage range
