IS5005 IFM Inductive Sensor

Sensing Distance 15 mm Usage For Industrial Body Material PBT plastic Output PNP Voltage 30 V Current 15mA Switching Function Normally open (NO) Brand IFM Sensor Type Inductive Sensor Model Name/Number IS5005 Product Type Sensor Material Plastic Usage/Application Industrial Dimension 27.8 x 10.2 x 16 Response frequency 50 Hz Power supply voltage 10 ..... 30 V Control output PNP Protection circuits IP56 Operating Frequency 50 Hz Power 10 A Dimension (W x H x L) 27.8 x 10.2 x 16 Leakage Current Load 25 mA Maximum Switching Current 35mA Color Orange Weight 130 g Inductive sensorIS5005IS-3002-BPKG/6M Particularly space-saving rectangular housing For use where space is restricted Very high switching frequency Wide operating temperature range Clearly visible indication of the switching status
