KA300 SINO Linear Encoder – KMSPARE Link Pvt Ltd

Usage/Application Machines tool Material Glass scale Length 70mm -1020mm Size Size KA300 / KA500 Model Name/Number sino Type Glass type Resolution 5/ 1 micron Cable Length 3mt Protection Class IP53 encoder output TTL (A,B,Z) In optical systems, the light source and lens produce a parallel beam of light which passes through four windows of the scanning reticle. The four scanning windows are shifted 90 degrees apart. The light then passes through the glass scale and is detected by photo sensors
