KTM-WP11181P Sick Contrast Sensor

Submit Requirement Detection Distance 10mm Brand Sick Sensing Method Contrast Sensors Switching Output NPN Model Number KTM-WP11181P Application Industrial Sensing Distance 10 mm Connection Type Cable Supply Voltage 12 to 24 V DC Housing Material Plastic Degree of Protection IP68 Operating Temperature -40 to 125 Deg C IP Rating IP68 Model No. KTM-WP11181P Weight 20 g Dimensions (W x H x D) 12 mm x 31.5 mm x 21 mm Sensing distance ? 12.5 mm Sensing distance tolerance ± 3 mm Housing design Small Light source LED, RGB 1) Wave length 470 nm, 525 nm, 625 nm Light emission Long side of housing Light spot size 1.6 mm x 9.5 mm Light spot direction Vertical 2) Receiving filters None Adjustment Teach-in button Teach-in mode 2-point teach-in static/dynamic + proximity to mark ET: Teach-in dynamic
