LD48J LIRRD Digital Preset Counter

Model Name/Number LD48J Display Type LCD Usage/Application Industrial Brand LIRRD Size 10 mm Color Black Type Digital Preset Counter Current Input 51 mA Input Voltage 24 V Ip Rating IP64 Range 10 mm Weight 3.2 Kg Frequency 50 /60 Hz Operating Temp. -20 ..... 60 C Accuracy 100 % Rated Supply Voltage 24 V (1) Counting the input signal (NPN knot signal, contact signal). (2) Battery backup function can be chosen.Data keep time after power cut should not less than 10 years (EEPROM). (3) Up digit (plus counting) or low digit (minus countring) panel dial code for selection. Three kinds of counting multiplying factor the counting range highly up to 1-999900. (4) 4 bits dial code preset, 1 bit dial code to set counting multiplying factor, LED with high bright displays counting value and the digit height is 0.36 inch. (5) lnput signal adopts photoelectric coupling isolation to increase the anti-interference capability. (6) DIN(48mm x 48mm) standard panel dimension, with standard 8-pin interface,and is converient to use with matchable base.
