LL3-TB01 Sick Fiber Optic Cable

Device type Fiber-optic cables Functional principle Through-beam system Fiber-optic head design Threaded sleeve Application Standard Compatible fiber-optic amplifiers WLL80, WLL180, GLL170(T), WLL24 Ex Sensing range max. 3,600 mm (Sensing range of WLL80 at 8 ms) Minimal object diameter 0.5 mm 1) Optical fiber head Angle of dispersion 60° Integrated lens No Compatibility tip adapters Yes Optical fiber Compatibility with infrared light No Optical fiber cable can be shortened ? Adapter end sleeves required No Included with delivery Mounting, 4 x M4 hexagon nut, 4 x washer, FC fiber cutter (5304141) 1) Minimum detectable object was determined at optimum measuring distance and optimum setting.
