LM-EX IDEM Safety Interlock Switch

Switch Type DPST Material/Body Metal Model Name/Number LM-EX Operating Temperature -25 ....... +55 C Maximum working frequence 150 kHz Model No. LM-EX Product Type Safety Interlock Switch Weight 75 g Accuracy 100 % Color Silver Safety Contacts 2 N/C IDEM's LM-Ex Explosion Proof Non Contact Switch is manufactured in Stainless Steel 316 with a mirror polished finish and has been designed to interlock hinged, sliding or removal guard doors or hatches.The LM-Ex comes equipped with highly reliable power reed switching elements, contacts de-rated and protected by internal fuses with high tolerance to guard misalignment.All electrical switching contacts are fully encapsulated within the switch and have a Stainless Steel 316 back plate to prevent tampering with the internal components.Manufactured with a magnetic sensing system which provides a wide sensing distance and provides a high tolerance to misalignment after sensing. The LM-Ex can be fitted behind stainless steel fittings and can operate in extreme environments of temperature and moisture.Available pre-wired with 5m or 10m cable with 2NC 1NO circuits.
