LMT121 IFM Point Level Sensor
LMT121 IFM Point Level Sensor
Order now and get it delivered to you !!!!
Regular price
Rs. 0.00
Regular price
Sale price
Rs. 0.00
Unit price
/
per
×
Get a quotation Now
Whatsapp Us
Whatsapp Us
Whatsapp or Call @ +91-9773819900
| Number of inputs and outputs | Number of digital outputs: 2 |
| Factory setting | media with low water content |
| Process connection | threaded connection G 1/2 sealing cone |
Application
| Special feature | Gold-plated contacts | ||
| Media | Liquids; viscous media; powder | ||
| Cannot be used for | See the operating instructions, chapter "Function and features". | ||
| Probe length[mm] | 11 | ||
| Tank pressure |
|
||
| MAWP for applications according to CRN[bar] | 40 |
| Oil | |
|---|---|
| Medium temperature[°C] | -40...100 |
| Medium temperature short time[°C] | -40...150; (1 h) |
| Water | |
|---|---|
| Medium temperature[°C] | -40...100 |
| Medium temperature short time[°C] | -40...150; (1 h) |
Electrical data
| Operating voltage[V] | 18...30 DC |
| Current consumption[mA] | < 50 |
| Protection class | III |
| Reverse polarity protection | yes |
| Measuring principle | capacitive |
Inputs / outputs
| Number of inputs and outputs | Number of digital outputs: 2 |
Outputs
| Total number of outputs | 2 |
| Output signal | switching signal; IO-Link |
| Electrical design | PNP/NPN |
| Number of digital outputs | 2 |
| Output function | normally open / normally closed; (parameterisable) |
| Max. voltage drop switching output DC[V] | 2.5 |
| Permanent current rating of switching output DC[mA] | 100 |
| Short-circuit protection | yes |
| Type of short-circuit protection | pulsed |
| Overload protection | yes |
Measuring/setting range
| Factory setting | media with low water content |
Response times
| Response time[s] | < 0.5 |
Interfaces
| Communication interface | IO-Link | ||||
| Transmission type | COM2 (38,4 kBaud) | ||||
| IO-Link revision | 1.1 | ||||
| SDCI standard | IEC 61131-9 | ||||
| SIO mode | yes | ||||
| Required master port type | A | ||||
| Process data analogue | 1 | ||||
| Process data binary | 2 | ||||
| Min. process cycle time[ms] | 2.3 | ||||
| Supported DeviceIDs |
|
Operating conditions
| Ambient temperature[°C] | -40...85 | |||
| Note on ambient temperature |
|
|||
| Storage temperature[°C] | -40...85 | |||
| Protection | IP 68; IP 69K |
