LR-W500 Keyence Self-Contained Full-Spectrum Sensor

Usage/Application Industrial Automation Grade Automatic Color Wight Model LR-W500 Detecting distance 30 to 500 mm Light source White LED Model LR-W500 Type 2 m cable type Detecting distance 30 to 500 mm Min. spot diameter Adjustable spot Approx. ø3.5 mm at 100 mm Approx. ø9 mm at 250 mm Approx. ø18 mm at 500 mm Light source White LED Mutual interference reduction function Up to 2 units when alternate frequencies set Timer OFF/ON delay/OFF delay/One-shot Response time 200 µs/1 ms/10 ms/100 ms/500 ms selectable *1 I/O Control output NPN open collector/PNP open collector selectable 30 VDC or less, 50 mA or less, remaining voltage: 2 V or less N.O./N.C. selectable *2 External input Tuning /Transmission OFF selectable Short circuit current: 1 mA or less for NPN/2 mA or less for PNP For the applied voltage, see the wiring diagrams in the instruction manual. For the input times, see the time charts in the instruction manual. *2 Protection circuit Protection against reverse power connection, power supply surge, output overcurrent, output surge, and reverse output connection Power supply Power voltage 10 to 30 VDC, including 10% ripple (P-P), Class 2 or LPS Current consumption 65 mA or less (without load) at 24 VDC; 120 mA or less (without load) at 12 VDC *3 Environmental resistance Enclosure rating IP65/IP67 (IEC60529) Ambient light Incandescent lamp: 10,000 lux or less, Sunlight: 20,000 lux or less Ambient temperature -20 to +50 °C (No freezing) Relative humidity 35 to 85 % RH (No condensation) Vibration resistance 10 to 55 Hz, Double amplitude 1.5 mm, 2 hours in each of the X, Y, and Z directions Shock resistance 1,000 m/s2, 6 times in each of the X, Y, and Z directions Material Case: Zinc die cast (Nickel chrome plating), Indicator cover: PPSU, Buttons: PES Lens cover and display: PMMA (scratch-resistant coating), Cable bushing: PBT, Cable: PVC, Spot adjustment dial: Iron (triiron tetraoxide coated) Weight Approx. 170 g (including cable)
