LS-H91-A Panasonic Photoelectric Sensor

Material PBT Accuracy 100% Activation current 10 mA Active Area 10 mm Operating temperature -25 ...... +55 C Model No. LS-H91-A Brand Panasonic Product Type Sensor Sensor Type Photoelectric Sensor Cable Length 2 m Ambient temperature -10 ....... +55 C Weight 30 g Product Number LS-H91-A Part Number LS-H91-A Products Name Digital Laser Sensor Product details Sensor head (Coaxial retroreflective type) The price of the product Please contact our office Applicable amplifiers LS-401(P), LS-401(P)-C2, LS-403 Sensing range:U-LG mode 0.1 to 5 m 0.328 to 16.404 ft (Note) The sensing range is the value for the RF-330 reflector. In addition, the sensing range is the possible setting range for the reflector. The sensor can detect an object less than 0.1 m 0.328 ft away. Note that if there are white papers or specular objects near the sensor head, reflected light from these objects may be received. In such cases, use the M.G.S. function of the amplifier unit to change the response time or incident light sensitivity.
