M08T4E2-PSM30G-S49G Balluff Inductive Sensor

Dimension Ø 8 x 54 mm Ø 8 x 49 mm Series M08 M08 Installation non-flush non-flush Connection Connector, M8x1-Male, 3-pin Connector, M8x1-Male, 3-pin Switching output PNP normally open (NO) Push-pull NO(PNP)/NC(NPN) Switching frequency 100 Hz 100 Hz Sensitivity Switching distance adjustable Switching distance adjustable Housing material 1.4301 stainless steel 1.4404 stainless steel Material sensing surface PTFE PBT Ambient temperature -10...70 °C -20...85 °C Operating voltage Ub 11...30 VDC 10...30 VDC Approval/Conformity CE cULus WEEE UKCA CE WEEE cULus IP rating IP65 IP67
