ML-7100B Solon Limit Switch

No. of Ports 4 Ports Switch Type Micro Limit Switch Rated Voltage 240 VAC Cable Length 2 m Model Name/Number ML-7100B Operating Frequency 50/ 60 Hz Ambient Operating Temperature -10....... +55 C Frequency 60 Hz Packaging Type Box Rated Insulation Voltage 12 - 24 V Weight 1.3 Kg Degree Of Protection IP67 Product type Limit Switch Contact type : 1a1b 2. Contact resistance (Initial ): 20m max. 3. Insulating resistance (Initial ): 100M @500VDC 4. Dielectric strength : between non-continuous terminals : 1,500VAC/1minute, 50/60Hz. between current-carrying metal parts and ground, and between each terminal and non-current-carrying parts ( , ): 2,000VAC/1 minute, 50/60Hz. 5. Vibration resistance (Malfunction ): 55Hz max. @1.5mm, double amplitude. 6. Shock resistance (Malfunction ): 98m/s @10G max. (Destruction ): 294m/s@30G max. 7. Ambient temperature : -20 C to +60 C @ RH 90% max. 20 C 8. Life expectancy : Mechanical - 10,000,000 operations min. (120 cpm) Electrical - 200,000 operations min. (120 cpm)
