ML6-8-H-150-RT/59/65A/115/136 P&F Photoelectric Sensor

Material ABS Accuracy 100 % Activation current 15 mA Active Area 20 mm Operating temperature -40 ....... 85 C Model No. ML6-8-H-150-RT/59/65a/115/136 Brand P&F Product type Sensor Sensor Type Photoelectric Sensor Supply current 25 mA Weight 50 g Sensing Distanse 30 mm General specifications Detection range 15 ... 150 mm Detection range min. 10 ... 30 mm Detection range max. 18 ... 150 mm Adjustment range 30 ... 150 mm Reference target standard white, 100 mm x 100 mm Light source LED Light type modulated visible red light , 660 nm Black/White difference (6 %/90 %) < 15 % Diameter of the light spot approx. 6 mm at detection range 150 mm Ambient light limit Continuous light 40000 Lux Modulated light 5000 Lux Functional safety related parameters MTTFd 1940 a Mission Time (TM) 20 a
