ML8-8-H-100-RT/65A/102/143/162 P&F Photoelectric Sensor

Material PBT Accuracy 100 % Activation current 30 mA Active Area 20 m Operating temperature -20 ........... 70 C Model No. ML8-8-H-100-RT/65a/102/143/162 Brand P&F Product Type Sensor Sensor Type Photoelectric Sensor Weight 10 g Protection IP67 Operating voltage 10 - 30 V Color Black General specifications Detection range 20 ... 100 mm Detection range min. 10 ... 25 mm Detection range max. 25 ... 100 mm Adjustment range 25 ... 100 mm Reference target standard white, 100 mm x 100 mm Light source LED Light type modulated visible red light , 640 nm Black/White difference (6 %/90 %) < 20 % Diameter of the light spot 2 light spots, 12 mm apart, spotsize 4 mm at a distance of 50 mm, 25 mm apart, spotsize 10 mm at a distance of 100 mm (outer spot to outer spot) Ambient light limit EN 60947-5-2 Functional safety related parameters MTTFd 794 a Mission Time (TM) 20 a Diagnostic Coverage (DC) 0 % Indicators/operating means Function indicator 2 LEDs yellow, light up in case of detection
