ML8-8-H-100-RT/65A/103/115/162 P&F Photoelectric Sensor

Sensing Distance 20 mm Usage For Industrial Body Material PBT plastic Brand P&F Model Name/Number ML8-8-H-100-RT/65a/103/115/162 Usage/Application Industrial Output Type PNP Switching Frequency 50/ 60 Hz Product Type Sensor Material PBT Power supply voltage 10 - 30 V Protection circuits IP67 Accuracy 100 % Operating Frequency 60 Hz Power 5 A Ambient Temperature -20 ...... 60 C Model No. ML8-8-H-100-RT/65a/103/115/162 Product Sensor type Photoelectric Sensor Weight 50 g General specifications Detection range 20 ... 100 mm Detection range min. 10 ... 25 mm Detection range max. 25 ... 100 mm Adjustment range 25 ... 100 mm Reference target standard white, 100 mm x 100 mm Light source LED Light type modulated visible red light , 640 nm Black/White difference (6 %/90 %) < 20 % Diameter of the light spot 2 light spots, 12 mm apart, spotsize 4 mm at a distance of 50 mm, 25 mm apart, spotsize 10 mm at a distance of 100 mm (outer spot to outer spot) Ambient light limit EN 60947-5-2 Functional safety related parameters MTTFd 794 a Mission Time (TM) 20 a Diagnostic Coverage (DC) 0 %
