ML8-8-H-30-RT/102/115/162 P&F Background Suppression Sensor

Sensing Distance 8 mm Usage For Industrial Body Material Stainless Steel Brand P&F Model Name/Number ML8-8-H-30-RT/102/115/162 Usage/Application Industrial Switching Frequency 60 Hz Product Type Background suppression sensor Material PBT Nominal Voltage 10 .....3 0 V Response frequency 60 Hz Power supply voltage 30 V Accuracy 100 % Ambient Temperature -40 ........ 70 C Detection range 15 ... 30 mm Reference target standard black, 100 mm x 100 mm Light source LED Light type modulated visible red light , 640 nm Black/White difference (6 %/90 %) < 10 % Diameter of the light spot 3 light spots, 12 mm apart (outer spot to outer spot), spotsize 3.5 mm at a distance of 30 mm Ambient light limit EN 60947-5-2 Functional safety related parameters MTTFd 794 a Mission Time (TM) 20 a Diagnostic Coverage (DC) 0 % Indicators/operating means Function indicator 2 LEDs yellow, light up in case of detection Electrical specifications Operating voltage UB 10 ... 30 V DC , class 2 Ripple max. 10 %
