MS325 ABB Manual Motor Starter | KMSPARE LINK PVT LTD

Electrical design PNP/NPN Output function normally open Dimensions[mm] 30.5 x 5 x 6.5 Electrical data Operating voltage[V] 5...120 AC/DC Protection class II Reverse polarity protection yes Reverse polarity protection yes Outputs Electrical design PNP/NPN Output function normally open Max. voltage drop switching output DC[V] 5 Max. voltage drop switching output AC[V] 5 Permanent current rating of switching output AC[mA] 100; (External protective circuit for inductive load (valve, contactor, etc.) necessary.) Permanent current rating of switching output DC[mA] 100; (External protective circuit for inductive load (valve, contactor, etc.) necessary.) Switching frequency AC[Hz] 1000 Switching frequency DC[Hz] 1000 Max. switching power[W] 10 Short-circuit protection no Short-circuit proof no Overload protection no Detection zone Response sensitivity[mT] 3.8 Travel speed[m/s] 10 Accuracy / deviations Hysteresis[mm] 1 Repeatability[mm] -0.2...0.2 Response times Max. fall time[ms] 0.1 Max. make time incl. bounce[ms] 0.6 Operating conditions Ambient temperature[°C] -25...70 Protection IP 65; IP 67
