ICC241 MTL Loop Powered Isolator

Phase Single Phase Brand MTL Model Name/Number ICC 241 Input signal 4 to 20mA Isolation between input and outpu 1500 V Weight 1 Kg MTL Instrument ICC 241 ICC241 Current To Current Loop Powered Isolator Eliminates Earthing Problems, Input signal 4 to 20mA Output signal 4 to 20mA, Isolation between input and output 1500V DC/AC Number of Channels: Single Channel Model Name/Number: ICC 241 Mounting Type: T- or G-section DIN-rail Input signal: 4 to 20mA Output signal: 4 to 20mA Isolation between input and output: 1500V DC/AC Operating Temperature: -20 DegreeC to +55 DegreeC Response Time: To reach 90% of span: 40ms, To reach 99.9% of span: 100ms Terminals: Accommodate 2.5mm2 conductors
