NBB15-30GM50-WO P&F Inductive Sensor

Sensing Distance 8 mm Usage For Industrial Output PNP Voltage 24 V Current 10mA Switching Function Normally open (NO) Brand P&F Sensor Type Inductive Sensor Model Name/Number NBB15-30GM50-WO Product Type Sensor Usage/Application Industrial Response frequency 50/60 Hz Body Material Stainless Steel Material Plastic Switching function Normally closed (NC) Output type Two-wire Rated operating distance sn 15 mm Installation quasi flush Output polarity AC Assured operating distance sa 0 ... 12.15 mm Actual operating distance sr 13.5 ... 16.5 mm Reduction factor rAl 0.33 Reduction factor rCu 0.28 Reduction factor r304 0.81 Output type 2-wire Nominal ratings Operating voltage UB 20 ... 253 V Switching frequency f 0 ... 20 Hz Hysteresis H typ. 5 % Reverse polarity protection reverse polarity tolerant
