NBN15-30GM50-E2-V1 P&F Inductive Sensor | Industrial Sensors – KMSPARE

P&F NBN15-30GM50-E2-V1 Inductive Sensor – High-Speed Sensing with Extended Range

The P&F NBN15-30GM50-E2-V1 is a high-performance inductive sensor designed for demanding industrial environments. With a generous 15 mm sensing distance and rugged IP67-rated stainless steel housing, this sensor offers reliable performance even under extreme temperatures and challenging conditions.

Key Features:

• Model: NBN15-30GM50-E2-V1

• Sensing Distance: 15 mm (non-flush)

• Output Type: NPN (Control Output: PNP also supported)

• Switching Function: Normally Open (NO)

• Voltage Range: 10 – 30 V DC

• Current Consumption: 10 mA

• Operating Frequency: 1150 Hz

• Response Frequency: 1150 Hz

• Weight: 136 g

Durable & Versatile Design:

• Body Material: Stainless Steel

• Sensor Material: Plastic

• Protection Class: IP67 – Suitable for harsh industrial conditions

• Operating Temperature: -40 °C to +85 °C

• Flexible Mounting: Versatile installation options for a range of industrial setups

Why Choose This Sensor?

• Extended sensing range for greater flexibility

• Fast switching response suitable for high-speed automation

• Built to perform in both standard and extreme temperature conditions

• Ideal for use in tight or restricted spaces due to compact cylindrical housing

Applications:
This sensor is ideal for automated machinery, process control, packaging lines, material handling, and industrial environments requiring robust sensing in variable temperatures.
