NBN8-18GM60-A0 P&F Inductive Sensor

Sensing Distance 15 mm Usage For Industrial Output NPN Voltage 30 V Current 15mA Switching Function Normally open (NO) Brand P&F Sensor Type Inductive Sensor Model Name/Number NBN8-18GM60-A0 Product Type Sensor Usage/Application Industrial Power supply voltage 12 ..... 24 V Control output NPN Temperatue -40 .......... 85 C Body Material Stainless Steel Material Plastic Switching function complementary Output type NPN Rated operating distance sn 8 mm Installation non-flush Output polarity DC Assured operating distance sa 0 ... 6.48 mm Reduction factor rAl 0.45 Reduction factor rCu 0.4 Reduction factor r304 0.75 Nominal ratings Operating voltage UB 10 ... 30 V Switching frequency f 0 ... 700 Hz
