NBN8-18GM60-W0 P&F Inductive Sensor

Sensing Distance 15 mm Usage For Industrial Output PNP Voltage 24 V Switching Function Normally open (NO) Brand P&F Sensor Type Inductive Sensor Model Name/Number NBN8-18GM60-W0 Product Type Sensor Usage/Application Industrial Response frequency 50/60 Hz Power supply voltage 10 -30 V Protection circuits IP60 Body Material Stainless Steel Current 15mA Material Plastic Control output 10 mA NBN8-18GM60-W0 P&F Inductive sensorSwitching function Normally closed (NC) Output type Two-wire Rated operating distance sn 8 mm Installation non-flush Output polarity AC Assured operating distance sa 0 ... 6.48 mm Actual operating distance sr 7.2 ... 8.8 mm typ. 8 mm Reduction factor rAl 0.4 Reduction factor rCu 0.4 Reduction factor r304 0.7 Output type 2-wire Nominal ratings Operating voltage UB 20 ... 253 V Switching frequency f 0 ... 20 Hz Hysteresis H typ. 7.5 %
