NBN8-18GM60-WS P&F Inductive Sensor

Sensing Distance 15 mm Usage For Industrial Output NPN Voltage 30 V Current 15mA Switching Function Normally open (NO) Brand P&F Sensor Type Inductive Sensor Model Name/Number NBN8-18GM60-WS Product Type Sensor Usage/Application Industrial Response frequency 20 Hz Power supply voltage 20 ...... 225 V Protection circuits IP67 Operating Frequency 20 Hz Leakage Current Load 15 mA Body Material Stainless Steel Material Plastic Switching function Normally open (NO) Output type Two-wire Rated operating distance 8 mm Installation non-flush Output polarity AC Assured operating distance 0 ... 6.48 mm Actual operating distance 7.2 ... 8.8 mm typ. 8 mm Reduction factor rAl 0.4 Reduction factor rCu 0.4 Reduction factor r304 0.7 Output type 2-wire
