NF5008 IFM Inductive Sensor

IFM NF5008 Inductive Sensor – Compact, Intrinsically Safe & Built for Industrial Reliability

The IFM NF5008 inductive sensor delivers high-performance object detection in hazardous and space-constrained industrial environments. With a rugged stainless steel body and intrinsically safe NAMUR design, it offers dependable operation under tough conditions and high switching demands.

Key Features:

• Sensing Distance: 5 mm

• Switching Function: Normally Open (NO)

• Output Type: NPN

• Model: NF5008 (IFA2004-N/6M/1D/1G)

• Power Supply Voltage: 10 – 30 V DC

• Operating Frequency: 60 Hz

• Response Frequency: 50 Hz

• Current Consumption: 10 mA

• Leakage Current Load: 20 mA

• Maximum Switching Current: 30 mA

• Power Rating: 10 A

Durable & Compact Construction:

• Dimensions: M12 x 1 / Length = 30 mm

• Body Material: Stainless Steel with Plastic Elements

• Color: Silver & Blue

• Weight: 254.5 g

• Protection Class: IP67 – Sealed against dust and water ingress

Advanced Features:

• NAMUR Certified Sensor – Safe for intrinsically safe circuits

• Explosion Protection: Suitable for hazardous areas

• Very High Switching Frequency: Enables fast, precise detection

• Short Housing: Perfect for installations with limited space

• Robust Build: Designed for longevity in demanding industrial settings

Applications:
Ideal for hazardous environments, automation systems, and compact machinery where space, safety, and performance are critical.
