NG5001 IFM Inductive Sensor

IFM NG5001 Inductive Sensor – High-Speed, Compact & Intrinsically Safe

The IFM NG5001 inductive sensor is a high-performance solution tailored for industrial applications in hazardous areas. With a compact housing, high switching frequency, and robust protection features, it’s ideal for precise detection in tight and demanding environments.

Key Features:

• Sensing Distance: 5 mm

• Switching Function: Normally Open (NO)

• Output Type: PNP

• Model: NG5001 (IG-2005-N/1D/1G)

• Power Supply Voltage: 10 – 36 V DC

• Operating Frequency: 720 Hz

• Response Frequency: 50 Hz

• Maximum Switching Current: 30 mA

• Current Consumption: 5 mA

• Leakage Current Load: 20 mA

• Power Rating: 10 A

Compact & Durable Construction:

• Housing Dimensions: M18 x 1 / Length = 33 mm

• Body Material: PBT Plastic

• Color: Orange

• Weight: 147 g

• Protection Rating: IP67 – Fully sealed for harsh industrial conditions

Advanced Features:

• NAMUR Sensor – For intrinsically safe circuit applications

• Explosion Protection: Ideal for hazardous environments

• High Switching Frequency: Ensures fast, accurate detection

• Short Housing: Perfect for space-constrained installations

• Rugged Design: Built to withstand challenging industrial environments

Applications:
Suited for hazardous zones, compact machinery layouts, and fast-paced automation systems requiring safe and accurate object detection.
