NI5002 IFM Inductive Sensor | Industrial Sensors – KMSPARE

IFM NI5002 Inductive Sensor – Compact, Safe, and Industrial-Grade

The IFM NI5002 inductive NAMUR sensor is designed for hazardous industrial environments, offering accurate detection with a 10 mm sensing range and PNP normally open output. Its compact stainless steel housing and high protection rating make it ideal for space-restricted and rugged applications.

🔧 Technical Specifications:

• Model: NI5002

• Brand: IFM

• Sensor Type: Inductive NAMUR Sensor

• Output Type: PNP, Normally Open (NO)

• Sensing Distance: 10 mm

• Voltage Range: 10 – 30 V DC

• Current Consumption: 15 mA

• Max. Switching Current: 30 mA

• Leakage Current Load: 20 mA

• Response Frequency: 50 / 60 Hz

• Operating Frequency: 50 / 60 Hz

• Protection Class: IP56

• Body Material: Stainless Steel

• Housing Material: Plastic

• Dimensions: M30 x 1.5 / L = 41 mm

• Weight: —

• Color: —

✅ Key Features:

• Certified NAMUR sensor for use in hazardous areas

• Short, space-saving design for tight installations

• Stainless steel construction for enhanced durability

• Reliable position detection in harsh environments

• Designed for intrinsically safe circuits

Ensure safe and efficient detection in demanding industrial setups with the IFM NI5002 Inductive Sensor – your trusted solution for compact sensing in hazardous zones.
